High Performance Hydraulic Thick Wall Hot Bender Machine
With the development of pipe fittings manufacturing, the technique of High Performance Hydraulic Thick Wall Hot Bender Machine also keep developing. Now the pipe fittings manufacturing technique that local pipe fitting factory adopts is nearly consistent with abroad same trade, some manufactures technique in this line has reached to top level.
The specifications of High Performance Hydraulic Thick Wall Hot Bender Machine is:
- Production Range: OD21mm-1620mm
- Radius: 2.5D-100D
- Thickness: 10mm-80mm
- Material: Carbon Steel, Alloy Steel, Stainless Steel
- Drive Type: Hydraulic, Chain
Features of High Performance Hydraulic Thick Wall Hot Bender Machine is:
- Slide rail design to make support board running more smooth.
- Slop steel clamp is a special technology in fully automatic bending machine. With such design, clamp tightening is more strong, more pushing forward more tight at end.
Welcome to contact us for High Performance Hydraulic Thick Wall Hot Bender Machine. We also produce and sell elbow forming machine, hydraulic press machine, pipe expanding machine, bevel machine etc. We have confidence to offer you favorable price and high quality machine.
Item |
Type |
Pipe OD(mm) |
Max.thickness(mm) |
Max.pushing power(t) |
Medium frequency power(KVA) |
M.F transformer(KVA) |
1 |
HYG-200 |
76-219 |
16 |
|
100 |
500 |
2 |
HYG-300 |
76-325 |
16 |
65 |
160 |
1000 |
3 |
HYG-400 |
108-426 |
16 |
84 |
200 |
1000 |
4 |
HYG-500 |
159-529 |
16 |
106 |
250 |
1000 |
5 |
HYG-600 |
159-630 |
18 |
130 |
300 |
1000 |
6 |
HYG-700 |
219-720 |
18 |
160 |
400 |
2000 |
7 |
HYG-800 |
219-820 |
18 |
206 |
450 |
2000 |
8 |
HYG-1000 |
426-1020 |
20 |
258 |
500 |
3000 |
9 |
HYG-1200 |
426-1220 |
20 |
300 |
600 |
3000 |
10 |
HYG-1400 |
426-1420 |
20 |
337 |
800 |
3000 |
