Bending machine for metal pipe
Bending machine for metal pipe shows a new era in pipe fittings industries.
Producing Scope about Bending machine for metal pipe:
- Production Range: OD21mm-1620mm
- Radius: 2.5D-100D
- Thickness: 10mm-80mm
- Material: Carbon Steel, Alloy Steel, Stainless Steel
- Drive Type: Hydraulic, Chain
The features about Bending machine for metal pipe:
- Bender has precise tolerence after bending by Bending machine for metal pipe. Because all bending process is by PLC control. End user need to put element information to PLC system, like: Bender size, thickness, radius, pushing angle, raw mother pipe material etc.
- Integrated hydraulic system
- Infrared radiation thermometer, temperature control automatic tracking and obvious show.
- Slide rail design to make support board running more smooth.
- Slope steel clamp is a special technology in Fully automatic bending machine. With such design, clamp tightening is more strong, more pushing forward more tight end.
Welcome to visit HEI YAN INT'L DEVELOPMENT LIMITED. We are professional Bending machine for metal pipe, elbow machine, hydraulic press machine, pipe expanding machine, tee making machine, bevel machine manufacturer in China. Please contact with us.
Item |
Type |
Pipe OD(mm) |
Max.thickness(mm) |
Max.pushing power(t) |
Medium frequency power(KVA) |
M.F transformer(KVA) |
1 |
HYG-200 |
76-219 |
16 |
|
100 |
500 |
2 |
HYG-300 |
76-325 |
16 |
65 |
160 |
1000 |
3 |
HYG-400 |
108-426 |
16 |
84 |
200 |
1000 |
4 |
HYG-500 |
159-529 |
16 |
106 |
250 |
1000 |
5 |
HYG-600 |
159-630 |
18 |
130 |
300 |
1000 |
6 |
HYG-700 |
219-720 |
18 |
160 |
400 |
2000 |
7 |
HYG-800 |
219-820 |
18 |
206 |
450 |
2000 |
8 |
HYG-1000 |
426-1020 |
20 |
258 |
500 |
3000 |
9 |
HYG-1200 |
426-1220 |
20 |
300 |
600 |
3000 |
10 |
HYG-1400 |
426-1420 |
20 |
337 |
800 |
3000 |
