Induction seamless elbow bending machine:
Hei yan international development limited professionally manufacture Induction seamless elbow bending machine to meet customers needs.
Design of Induction seamless elbow bending machine:
there are two support rods,which were placed in the two brackets,the distance between the two brackets can be adjusted to suit the butt welding elbows in various diameters.the lifting platform placed in horizontal rails and can slipe on it. the upper parts of lift platform are equipped with clamp devices,the machine head placed on the top of lift platform,and can slide above.The top surface of machine head installed proximity switch that used for adjusting the tilt angle.
Induction seamless elbow bending machine consists of main cylinder,hydraulic pump station,axial plunger pump,motor,hydraulic pushing,stepless speed,induction heating power source.
Item |
OD(mm)
|
Max.Thickness(mm)
|
Cylinder(pc)
|
Max. pushing power(t)
|
Medium frequency(KW)
|
1 |
OD1420 |
20 |
4 |
670 |
700-800 |
2 |
OD1220 |
20 |
4 |
600 |
600-650 |
3 |
OD1020 |
20 |
4 |
500 |
550-600 |
4 |
OD820 |
20 |
4 |
400 |
500-550 |
5 |
OD720 |
20 |
4 |
320 |
450-500 |
6 |
OD630 |
20 |
2 |
300 |
400-450 |
7 |
OD530 |
14 |
2 |
160 |
350-400 |
8 |
OD426 |
14 |
2 |
130 |
300-350 |
9 |
OD325 |
14 |
2 |
84 |
200-250 |
10 |
OD219 |
12 |
2 |
65 |
160-200 |
