Hot Pipe Bender
1 Hot Pipe Bender is designed to bend large diameter pipe and different kinds of specifics pipe
2 According to customer need,the bending radius and angle can be adjusted freely.
3 The raw material can be: seamless pipe,welded pipe or rolled pipe
4 Bending range from outside diameter 108mm-1420mm,thickness 5mm-120mm
Hot Pipe Bender heats the pipe inductively over a small cross-section, while the pipe is mechanically driven through a watercooled induction ring. The bending of the pipe is caused by means of a rotating arm on a pivot that, at the same time, determines the radius of the bend. As the arm is completely free adjustable between its minimum and maximum radius..
Radius of hot pipe bender: 2.5D-10D
Thickness: 10mm-80mm
Material: Carbon steel, Alloy steel, Stainless steel
Drive type: Hydraulic, chain
Hei Yan Group is specilized in producing Hot Pipe Bender and can do according to customer requirements.For example:pipe expanding machine, pipe bending machine,bevel machine,we also can supply special specification machine according to customers requirements.
