Steel Elbow Hot Forming Machine
Steel Elbow Hot Forming Machine we adopts intermediate frequency power source to supply the energy. It can produce diameter 21mm-1420mm, wall thickness 3mm-80mm, over 1D carbon steel, alloy steel elbow.
Features of our 1.The elbow forming machine is fit for batch production.
2.It has intermediate frequency part and hydraulic part.
3.The pushing speed of the machine can be randomly adjusted.
4.The mandrel equipment for elbows has various designed ways, elbow making machine can be produce 2 piece of elbows in a time or support producing of elbow as well as 180 degree bend.
Steel Elbow Hot Forming Machine includes two system:
One is induction heating system, using 380V,50HZ three-phase alternating current, through thyristor to convert the frequency, to make 2500HZ medium frequency current, heating the raw material.
The other is hydraulic pushing system,.
Hydraulic system is composed with the following five main parts.
Energy device, it provide pressure oil for the hydraulic system, transform the mechanical power into hydraulic power. Normally type is hydraulic pump.
Execute device, it transform hydraulic power into mechanical power.Hydraulic cylinder, hydraulic motor, they are all called execute piece of hydraulic system.
Control adjustment device, it controls the pressure, flow rate or flow direction of the hydraulic system. I.e overflow valve, throttle valve, reversing valve, start-stop valve etc.
Auxiliary device, i.e oil tank, oil filter, oil pipeline etc. They are necessary to keep hydraulic system working well.
Working medium, that is hydraulic oil.
Welcome to contact with us for more information of Steel Elbow Hot Forming Machine,we also manufacture,pipe expanding machine,pipe bending machine,medium frequency heating equipment according to customer requirement.
