Electric bevel machine instruction
Electric bevel machine instruction can work with different clamps, machining scope: OD59-800mm pipes and elbow, bends.
Electric bevel machine instruction combined by Motive head, Knife wheel strutual, Lathe body, clamp panel, electric control system, total five parts
Main technical data
1、Motor power：N=7.5KW,n=960rpm
2、Wheel speed：n=31-161rpm 4 steps
3、Working scope：Pipe ODΦ159-Φ800mm Pipe thickness 10-150mm
4、Angle adjustment scope：between 0-35°
5、Axis moving speed：50-400mm/r
6、Axis moving stroke：300mm
7、Clamp working panel：1500×1200×150mm
8、Bevel type：single V、double V、U
9、OD of wheel：D=850mm
10、Center height of machine：H=1100mm
11、Weight of machine：G=5000kg
Electric bevel machine instruction increase efficiency in working. Hei Yan supply Electric bevel machine,simple bevel machine,double size bevel machine.
